    Lopolight 2NM Combined Sidelight – Horizontal Mount (Upside-Down), 2.5m Cable (Silver Anodised)

    [For vessels under 20m – LED navigation light]


    The Lopolight 2NM Combined Sidelight – Upside-Down Mount is designed for vessels under 20 metres where navigation lights need to be installed beneath a horizontal surface such as a bridge deck, pulpit, or hardtop overhang. It combines port (red) and starboard (green) sectors into a single compact housing, each projecting a 112.5° beam visible to 2 nautical miles.

    Available exclusively in silver anodised aluminium, this model is rugged, corrosion-resistant, and built for durability. Rated IP68, the epoxy-sealed electronics ensure long-term protection against saltwater, vibration, and UV exposure.

    The 2.5-metre marine-grade cable is pre-installed for straightforward connection to the vessel’s wiring system.

    Key Features:

    • Suitable for vessels under 20 metres
    • Combined port and starboard sidelights (112.5° each, visible to 2NM)
    • Upside-down horizontal mount – ideal for mounting beneath decks or structures
    • Available in Silver anodised aluminium housing only
    • IP68 sealed with epoxy-filled electronics for marine-grade durability
    • Supplied with 2.5m marine-grade cable
    • Low power draw – efficient LED output at 10–32 V
    • Fully compliant with COLREG72, EN14744, and USCG standards
    • Alternative versions available: standard horizontal mount model in Silver or Black anodised aluminium

    Spezifikationen

    Electrics
    Spannung unter Betrieb 10-32
    Power supply type dc.
    Current draw (mA @ 12VDC) 163
    Current draw (mA @ 24VDC) 90
    Leistung (W) 2.2
    Approved to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
    Luminous Intensity (cd) >5.4
    Operating temperature -25°C to 55°C
    Sichtweite (NM) 2
    Wasserdichtigkeit IP68
    Boat
    Boat size (m) 12–20 m
    Dimensions
    Dimensions (mm) Ø92,5mm x 46mm
    Rigging
    Feed wire gauge Min 0.5mm2 AWG22
    Material
    Material silber eloxiertes Aluminium 25µ, PMMA-Linse, A4-Edelstahlschrauben, Epoxidharz, Polyurethan
    Compatibility
    Connection 2,5 m Kabel
    Weight
    Gewicht (g) 650
    Garantie (Jahren) 5 Jahre eingeschränkte Garantie
