Lopolight 2NM Feu de côté combiné, montage hor. inversé

https://www.upffront.com/web/image/product.template/219903/image_1920?unique=ef590c2

536,40 536.4 USD 536,40

455,46 €

0% de réduction

Available on request

Jours
:
Heures
:
Minutes
:
Secs
  • Tension de fonctionnement
  • Power supply type
  • Current draw (mA @ 12VDC)
  • Current draw (mA @ 24VDC)
  • Power (W)
  • Approved to
  • Light colour
  • Light type
  • Luminous Intensity (cd)
  • Operating temperature
  • Visibility (NM)
  • Résistant à l'eau
  • Marque
  • Boat size (m)
  • Boat type
  • Dimensions (mm)
  • Feed wire gauge Min
  • Matériau
  • Connection
  • Montage
  • Poids (g)
  • Garantie (année)

Cette combinaison n'existe pas.

Product Image

Lopolight 2NM Feu de côté combiné, montage hor. inversé

536,40 536,40
0% Off
SKU:
N/A
Marque: Lopolight
Shipping Info

Garantie de remboursement de 30 jours

 Retours sous 14 jours

 Expédition express disponible

Partager :

Lopolight 2NM Combined Sidelight – Horizontal Mount (Upside-Down), 2.5m Cable (Silver Anodised)

[For vessels under 20m – LED navigation light]


The Lopolight 2NM Combined Sidelight – Upside-Down Mount is designed for vessels under 20 metres where navigation lights need to be installed beneath a horizontal surface such as a bridge deck, pulpit, or hardtop overhang. It combines port (red) and starboard (green) sectors into a single compact housing, each projecting a 112.5° beam visible to 2 nautical miles.

Available exclusively in silver anodised aluminium, this model is rugged, corrosion-resistant, and built for durability. Rated IP68, the epoxy-sealed electronics ensure long-term protection against saltwater, vibration, and UV exposure.

The 2.5-metre marine-grade cable is pre-installed for straightforward connection to the vessel’s wiring system.

Key Features:

  • Suitable for vessels under 20 metres
  • Combined port and starboard sidelights (112.5° each, visible to 2NM)
  • Upside-down horizontal mount – ideal for mounting beneath decks or structures
  • Available in Silver anodised aluminium housing only
  • IP68 sealed with epoxy-filled electronics for marine-grade durability
  • Supplied with 2.5m marine-grade cable
  • Low power draw – efficient LED output at 10–32 V
  • Fully compliant with COLREG72, EN14744, and USCG standards
  • Alternative versions available: standard horizontal mount model in Silver or Black anodised aluminium

Spécifications

Electrics
Tension de fonctionnement 10-32
Power supply type dc.
Current draw (mA @ 12VDC) 163
Current draw (mA @ 24VDC) 90
Power (W) 2.2
Approved to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
Luminous Intensity (cd) >5.4
Operating temperature -25°C to 55°C
Visibility (NM) 2
Résistant à l'eau IP68
Boat
Boat size (m) 12–20 m
Dimensions
Dimensions (mm) Ø92,5mm x 46mm
Rigging
Feed wire gauge Min 0.5mm2 AWG22
Material
Matériau Aluminium anodisé argent 25µ, lentille PMMA, vis inox A4, époxy, polyuréthane
Compatibility
Connection Câble 2,5 m
Weight
Poids (g) 650
Garantie (année) Garantie limitée 5 ans
