Lopolight 2nm luz de costado combinada, mont. hor. invertido

https://www.upffront.com/web/image/product.template/219903/image_1920?unique=ef590c2

536,40 536.4 USD 536,40

455,46 €

0% Descuento

No está disponible para venta

Días
:
Horas
:
Mins
:
Secs
  • Tensión de funcionamiento (V)
  • Tipo de alimentación
  • Consumo de corriente (mA @ 12VCC)
  • Consumo de corriente (mA @ 24VCC)
  • Potencia (W)
  • Homologado según
  • Color de la luz
  • Tipo de luz
  • Intensidad luminosa (cd)
  • Temperatura de funcionamiento
  • Visibilidad (NM)
  • Resistencia al agua
  • Marca
  • Eslora (m)
  • Tipo de embarcación
  • Dimensiones (mm)
  • Calibre de cable de alimentación Mín
  • Material
  • Conexión
  • Montaje
  • Peso (g)
  • Garantía (años)

Esta combinación no existe.

Product Image

Lopolight 2nm luz de costado combinada, mont. hor. invertido

536,40 536,40
0% Off
SKU:
N/A
Shipping Info

Devolución de dinero en 30 días

 14-días para devoluciones

 Envío rápido disponible

Compartir :

Lopolight 2NM Combined Sidelight – Horizontal Mount (Upside-Down), 2.5m Cable (Silver Anodised)

[For vessels under 20m – LED navigation light]


The Lopolight 2NM Combined Sidelight – Upside-Down Mount is designed for vessels under 20 metres where navigation lights need to be installed beneath a horizontal surface such as a bridge deck, pulpit, or hardtop overhang. It combines port (red) and starboard (green) sectors into a single compact housing, each projecting a 112.5° beam visible to 2 nautical miles.

Available exclusively in silver anodised aluminium, this model is rugged, corrosion-resistant, and built for durability. Rated IP68, the epoxy-sealed electronics ensure long-term protection against saltwater, vibration, and UV exposure.

The 2.5-metre marine-grade cable is pre-installed for straightforward connection to the vessel’s wiring system.

Key Features:

  • Suitable for vessels under 20 metres
  • Combined port and starboard sidelights (112.5° each, visible to 2NM)
  • Upside-down horizontal mount – ideal for mounting beneath decks or structures
  • Available in Silver anodised aluminium housing only
  • IP68 sealed with epoxy-filled electronics for marine-grade durability
  • Supplied with 2.5m marine-grade cable
  • Low power draw – efficient LED output at 10–32 V
  • Fully compliant with COLREG72, EN14744, and USCG standards
  • Alternative versions available: standard horizontal mount model in Silver or Black anodised aluminium

Especificaciones

Electrics
Tensión de funcionamiento (V) 10-32
Tipo de alimentación dc.
Consumo de corriente (mA @ 12VCC) 163
Consumo de corriente (mA @ 24VCC) 90
Potencia (W) 2.2
Homologado según COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
Intensidad luminosa (cd) >5.4
Temperatura de funcionamiento -25°C to 55°C
Visibilidad (NM) 2
Resistencia al agua IP68
Boat
Eslora (m) 12–20 m
Dimensions
Dimensiones (mm) Ø92,5mm x 46mm
Rigging
Calibre de cable de alimentación Mín 0.5mm2 AWG22
Material
Material Aluminio anodizado plata 25µ, lente PMMA, tornillos inox A4, epoxi, poliuretano
Compatibility
Conexión Cable 2,5 m
Weight
Peso (g) 650
Garantía (años) Garantía limitada de 5 años
