Vertically mounted with 2,5m cable
Included in package:
- 1 Navigation light
- precabled with 2.5 meter shielded marine grade cable
- 2 Mounting screws (M6 * 8 mm)
- Installation guide
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Spécifications
| Electrics | |
|---|---|
| Tension de fonctionnement | 10-32 |
| Power supply type | dc. |
| Current draw (mA @ 12VDC) | 163 |
| Current draw (mA @ 24VDC) | 90 |
| Power (W) | 2.2 |
| Approved to | COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR |
| Luminous Intensity (cd) | >5.4 |
| Operating temperature | -25°C to 55°C |
| Visibility (NM) | 2 |
| Résistant à l'eau | IP68 |
| Boat | |
|---|---|
| Boat size (m) | 12–20 m |
| Rigging | |
|---|---|
| Feed wire gauge Min | 0.5mm2 AWG22 |
| Material | |
|---|---|
| Matériau | Aluminium anodisé argent 25µ, lentille PMMA, vis inox A4, époxy, polyuréthane ou Aluminium anodisé noir 25µ, lentille PMMA, vis inox A4, époxy, polyuréthane |
| Undefined | |
|---|---|
| Couleur | Noir ou Argent |
| Compatibility | |
|---|---|
| Connection | Câble 2,5 m |
| Weight | |
|---|---|
| Poids (g) | 500 |
| Garantie (année) | Garantie limitée 5 ans |
