Spezifikationen
| Electrics | |
|---|---|
| Spannung unter Betrieb | 10-32 |
| Power supply type | DC |
| Current draw (mA @ 12VDC) | 167 |
| Current draw (mA @ 24VDC) | 110 |
| Approved to | COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR |
| Luminous Intensity (cd) | >5.4 |
| Operating temperature | -25°C to 55°C |
| Sichtweite (NM) | 2 |
| Wasserdichtigkeit | IP68 |
| Boat | |
|---|---|
| Boat size (m) | Unter 12 m oder 12–20 m oder 20–50 m |
| Dimensions | |
|---|---|
| Dimensions (mm) | See drawing |
| Material | |
|---|---|
| Material | silber eloxiertes Aluminium 25µ, PMMA-Linse, A4-Edelstahlschrauben, Epoxidharz, Polyurethan |
| Compatibility | |
|---|---|
| Connection | M12-Steckverbinder |
| Weight | |
|---|---|
| Gewicht (g) | 1500 |
