Specifications for Tylaska T16S Grillete de disparo con puente estándar
| Boat | |
|---|---|
| Eslora de barco recomendada - Máx (ft) | 50 |
| Eslora de barco recomendada - Mín (ft) | 40 |
| Estilo | Swivel Bail (Small) |
| Load | |
| SWL (kg) | 3630 |
| NBL (kg) | 7260 |
| Dimensions | |
| A (mm) | 22.9 |
| B (mm) | 20.1 |
| C (mm) | 120 |
| Material | |
| Material | Stainless Steel |
| Grado del material | 17-4PH SS |
| Weight | |
| Peso (g) | 258 |
Product specifications
are provided for guidance only, subject to error /
change and without warranty or guarantee. Refer to
manufacturer’s own datasheets / manuals for further
information.
Tylaska T16 Snap Shackles are perfect for applications requiring high strength and low weight. They have a SWL of 3,628kg and weigh only 258g in the standard bail configuration. Ideal for 40 to 50 foot boats. Standard Bails provide ample room for attaching a line while keeping weight and overall shackle length to a minimum. Ideal for halyards and sheets. Large Bails provide room for up to three additional shackles or a combination of shackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications.
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Especificaciones
| Boat | |
|---|---|
| Eslora de barco recomendada - Máx (ft) | 50 |
| Eslora de barco recomendada - Mín (ft) | 40 |
| Estilo | Swivel Bail (Small) |
| Load | |
|---|---|
| SWL (kg) | 3630 |
| NBL (kg) | 7260 |
| Dimensions | |
|---|---|
| A (mm) | 22.9 |
| B (mm) | 20.1 |
| C (mm) | 120 |
| Material | |
|---|---|
| Material | Stainless Steel |
| Grado del material | 17-4PH SS |
| Weight | |
|---|---|
| Peso (g) | 258 |
