Specifications for Antal U-Bolt - 10mm
| Boat | |
|---|---|
| Estilo | Fixed |
| Load | |
| SWL (kg) | 2500 |
| Dimensions | |
| D (mm) | 63 |
| d (mm) | 10 |
| Longitud (mm) | 67 |
| Material | |
| Material | Stainless Steel |
| Grado del material | AISI 316 |
| Weight | |
| Peso (g) | 170 |
Antal U-Bolt – 10mm
The Antal U-Bolt – 10mm is the strongest in the U-Bolt range, offering a Safe Working Load (SWL) of 2,500 kg. Manufactured from 316 stainless steel, it delivers excellent corrosion resistance and long-term durability while remaining simple and economical to install.
With only two fixing points, U-Bolts are a more basic solution than Antal’s Standard Padeyes, which at this size use four bolts to distribute loads more effectively into the deck. As a result, the U-Bolt is best suited for smaller yacht applications where loads are moderate, but for higher-stress situations the Standard Padeye is the better choice.
Features:
- 10mm gauge U-Bolt, SWL 2,500 kg
- Marine-grade 316 stainless steel construction
- Two-bolt fixing system
- Economical, easy-to-install deck fitting
- Corrosion-resistant and maintenance-free
Applications:
- Medium-to-heavy control line or block attachment points
- Lashings and tie-downs on smaller yachts
- Recommended for moderate loads; for maximum strength and load distribution, use Standard Padeyes
Especificaciones
| Boat | |
|---|---|
| Estilo | Fixed |
| Load | |
|---|---|
| SWL (kg) | 2500 |
| Dimensions | |
|---|---|
| D (mm) | 63 |
| d (mm) | 10 |
| Longitud (mm) | 67 |
| Material | |
|---|---|
| Material | Stainless Steel |
| Grado del material | AISI 316 |
| Weight | |
|---|---|
| Peso (g) | 170 |
