Specifications for Ropeye TDP 16 Deck Bushing
| Material | Anodised Aluminium |
| A (mm) | 32 |
| B (mm) | 12 |
| C (mm) | 16 |
| D (mm) | 30 |
| Weight (g) | 11 |
Ropeye TDP 16 Deck Bushing – Robust & Low-Friction Through-Deck Protection
The Ropeye TDP 16 Deck Bushing is a durable through-deck fitting designed to protect both the deck and running rigging from excessive wear. Crafted from anodised aluminium, it reinforces the deck while providing a smooth, low-friction passage for ropes, reducing chafing and extending line longevity.
Key Features:
✔ Prevents Deck & Rope Wear – Minimises friction and abrasion, helping to extend the lifespan of both the deck and rigging.
✔ Lightweight & Corrosion-Resistant – Made from anodised aluminium, ensuring long-term durability in marine environments.
✔ Deck Reinforcement – Strengthens the deck at the installation point, distributing loads more effectively.
✔ Smooth Rope Passage – Reduces resistance and friction on running lines for enhanced performance.
✔ Versatile & Functional – Designed for seamless integration into various rigging setups.
Applications:
- Ideal for protecting deck penetrations where ropes pass through.
- A key component for installing Loops, Twinlines, and soft rigging solutions.
- Suitable for both racing yachts and cruising setups where durability and efficiency are priorities.
Installation:
- Drill the installation hole to the correct size.
- Clean the area with acetone to ensure a solid and secure fit.
- Trim the Ropeye TDP 16 to match the deck thickness – the bushing has a standard length of 30mm and may need to be cut for a precise fit.
- Insert the Ropeye TDP 16 into place, ensuring proper alignment for optimal performance.
Warranty: This product comes with a 2-year warranty, providing confidence in durability and performance.
Specifications
| Material | Anodised Aluminium |
| A (mm) | 32 |
| B (mm) | 12 |
| C (mm) | 16 |
| D (mm) | 30 |
| Weight (g) | 11 |
