Upffront is pleased to announce the expansion of the Ronstan Orbit winches range with the introduction of the 45QT and 50QT models. These new additions are available in both 2-speed and 3-speed configurations, extending the capabilities of the established Ronstan Orbit platform.
Building on the proven 20ST, 30QT, and 40QT models, the latest Orbit winch sizes are designed to support a wider range of sailing yachts, particularly in the mid-to-larger size segment.
Ronstan Orbit Winch Key Features and Benefits
The Ronstan Orbit winch range is defined by a number of design features that focus on weight reduction, control, and serviceability.
Lightweight Construction: The Ronstan Orbit Winch series features fully machined aluminum drums, significantly reducing weight without compromising strength. This lightweight design contributes to improved boat performance and ease of handling.
Power Ribs Technology: Inspired by Andersen winches, the incorporation of Power Ribs ensures maximum line grip with minimal rope wear. This design requires fewer wraps around the drum, reduces the load on the self-tailer, and prevents riding turns, thereby extending the lifespan of your running rigging.
QuickTrim Self Tailing Feature: A standout innovation in the Ronstan Orbit Winch series is the patented QuickTrim feature, allowing sailors to ease lines without removing them from the self-tailer or disengaging the winch handle. By rotating the top cover counterclockwise, the self-tailer temporarily disengages, enabling smooth and controlled easing of the line. Releasing the cover re-engages the self-tailer, resuming normal operation. This functionality is particularly advantageous for making frequent minor adjustments to sheet and halyard tension, enhancing responsiveness to changing sailing conditions.
Ease of Maintenance: Ronstan Orbit Winches are designed for straightforward disassembly without the need for tools. A spring-loaded release latch allows for quick removal of the self-tailing arm and drum, facilitating easy cleaning and maintenance, which is essential for ensuring long-term reliability and performance.
Introducing the Ronstan Orbit Winch 45QT and 50QT Models
The new 45QT and 50QT winches cater to larger yachts, expanding the applicability of the Ronstan Orbit Winch series. Both models are available in 2-speed and 3-speed configurations, providing sailors with options to match their specific sailing requirements.
Ideal for general sailing purposes, 2-speed winches offer two gear ratios. The first gear provides rapid line retrieval under low load, while the second gear offers increased mechanical advantage for trimming under higher loads. This configuration suits most cruising and racing scenarios, delivering a balance between speed and power.
The 3-speed models introduce an additional high-speed gear, facilitating exceptionally rapid line retrieval during the initial stages of trimming or hoisting sails. This feature is particularly beneficial in racing situations where swift sail adjustments are crucial. The first gear engages with a fast 1.4:1 ratio for quick line recovery; as load increases, the winch shifts to the second and third gears, providing greater mechanical advantage for precise control under heavy loads.
Ronstan Orbit Winch Applications and Advantages
The choice between 2-speed and 3-speed winches depends on the specific demands of your sailing activities:
2-Speed Winches
Suitable for a wide range of sailing vessels, including cruisers and racers up to approximately 14 meters (45 feet). They offer simplicity and efficiency for standard sail handling tasks, making them a versatile choice for many sailors.
3-Speed Winches
Designed for performance-oriented sailors and larger yachts, these winches provide the extra speed necessary for rapid sail adjustments, which can be a decisive factor in competitive racing scenarios. The additional gear allows for quick initial line recovery, transitioning smoothly to higher torque as the load increases.
Ongoing Development of the Ronstan Orbit Range
The addition of the 45QT and 50QT models reflects a continued expansion of the Ronstan Orbit winches platform.
As deck layouts evolve—particularly with increased use of high-load, low-stretch line systems—winch design is also adapting. Future developments are likely to continue focusing on:
- weight optimisation
- improved ergonomics
- integration with modern rigging systems
Conclusion 45QT and 50QT Ronstan Orbit Winches
The latest 45QT and 50QT Ronstan Orbit winches extend an already well-defined product range into larger yacht applications.
With features such as QuickTrim, optimised drum geometry, and tool-free maintenance, the Orbit winch platform offers a technically considered approach to modern sail handling.
For owners evaluating upgrades or specifying new deck hardware, the choice between 2-speed and 3-speed configurations remains a key decision, driven by load requirements and sailing style.
If you have any questions about Ronstan Orbit Winches, please feel free to contact us and talk to one of our sailing experts or to view the full range of Ronstan Orbit Winches, click below:
