Specifications for Tylaska T5 Martin Breaker - Standard Bail Snap Shackle
| Material | Stainless Steel |
| Material Grade | 17-4PH SS |
| SWL (kg) | 1130 |
| NBL (kg) | 2270 |
| A (mm) | 13.5 |
| B (mm) | 12.7 |
| C (mm) | 76.7 |
| Weight (g) | 61 |
Tylaska T5 Martin Breaker – Standard Bail Snap Shackle
The Tylaska T5 Martin Breaker is the smallest model in the Martin Breaker range, designed specifically for boats in the 20–30 ft size bracket. Built from aerospace-grade 17-4 PH stainless steel and 100% proof-tested to its working load, it combines compact dimensions with outstanding strength and reliability.
The Martin Breaker system transforms the traditional trigger snap shackle into a remote-release unit, using a Dyneema® cord (pre-installed) to activate the release mechanism under load. This allows the tack of a spinnaker to be ejected instantly from a safe position—typically from the cockpit—removing the need for crew to move forward and manually “spike” the shackle on the bowsprit.
With a breaking load of 5,000 lb (2,270 kg), the T5 is perfectly suited to performance dinghies, sportsboats, and smaller keelboats where weight savings and safety are equally important. The standard swivelling bail provides versatile attachment while helping to reduce line twist, making it a reliable choice for spinnaker sheets, tack lines, or other static-load release applications.
Key Features
- Breaking load: 5,000 lb (2,270 kg)
- Ideal for boats: ~20–30 ft
- Material: Heat-treated 17-4 PH stainless steel for maximum strength and durability
- Release system: Pre-installed Dyneema® remote trigger cord for under-load release
- Bail type: Standard swivelling bail for flexible line and fitting compatibility
- Safety & performance: Enables safe, fast spinnaker takedowns without bow crew exposure
- Proof-tested: Each unit individually tested to working load
Typical Applications
- Spinnaker tack line release on small keelboats and sportsboats
- Remote-release setup for asymmetric spinnakers
- Short-handed or high-performance racing where safety and efficiency are critical
The Tylaska T5 Martin Breaker brings race-level safety and innovation to smaller yachts, offering the same precision engineering trusted on larger offshore racers, scaled for compact rigs.
Specifications
| Material | Stainless Steel |
| Material Grade | 17-4PH SS |
| SWL (kg) | 1130 |
| NBL (kg) | 2270 |
| A (mm) | 13.5 |
| B (mm) | 12.7 |
| C (mm) | 76.7 |
| Weight (g) | 61 |
