Specifications
| Electrics | |
|---|---|
| Operating voltage (V) | 20-32 |
| Power supply type | dc. |
| Current draw (mA @ 12VDC) | 270 |
| Current draw (mA @ 24VDC) | 176 |
| Approved to | COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR |
| Luminous Intensity (cd) | >15 |
| Operating temperature | -25°C to 55°C |
| Visibility (NM) | 3 |
| Water resistance | IP68 |
| Boat | |
|---|---|
| Boat size (m) | Over 50M |
| Dimensions | |
|---|---|
| Dimensions (mm) | See drawing |
| Compatibility | |
|---|---|
| Connection | M12 connector |
