Specifications for Antal Maxi Clutch V Grip 14
| Ropes | |
|---|---|
| Recommended line - Max Ø (mm) | 14 |
| Recommended line - Min Ø (mm) | 12 |
| Boat | |
| Type | Single |
| Load | |
| SWL (kg) | 1700 |
| Blocks | |
| Dimensions | |
| A (mm) | 63 |
| B (mm) | 137 |
| C (mm) | 23 |
| Fixing hole Ø (mm) | 10 |
| Height (mm) | 102 |
| Length (mm) | 223 |
| Width (mm) | 44 |
| Compatibility | |
| Weight | |
| Weight (g) | 1400 |
Product specifications
are provided for guidance only, subject to error /
change and without warranty or guarantee. Refer to
manufacturer’s own datasheets / manuals for further
information.
The Antal Maxi Clutch V Grip 14 is a robust line control system for large sailboats, well-suited for handling a single thicker control line (14mm) with exceptional grip and minimal line damage. The V-Grip system and the potential single clutch design make it a popular choice for critical control lines on large vessels
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Ropes | |
|---|---|
| Recommended line - Max Ø (mm) | 14 |
| Recommended line - Min Ø (mm) | 12 |
| Boat | |
|---|---|
| Type | Single |
| Load | |
|---|---|
| SWL (kg) | 1700 |
| Blocks |
|---|
| Dimensions | |
|---|---|
| A (mm) | 63 |
| B (mm) | 137 |
| C (mm) | 23 |
| Fixing hole Ø (mm) | 10 |
| Height (mm) | 102 |
| Length (mm) | 223 |
| Width (mm) | 44 |
| Compatibility |
|---|
| Weight | |
|---|---|
| Weight (g) | 1400 |
