Specifications for Lewmar Epsilon anchor ss 50kg
| Recommended chain size (mm) | 12 |
| Anchor weight (kg) | 50 |
| Recommended Boat size - Max (ft) | 82 |
| Recommended Boat size - Min (ft) | 70 |
| Material | Stainless Steel |
| Warranty (yrs) | Lifetime guarantee |
| A (mm) | 1175 (±24) |
| B (mm) | 520 (±10) |
| C (mm) | 20 |
| D (mm) | 890 (±18) |
| E (mm) | 479 (±10) |
| Weight (g) | 50000 |
Lewmar Epsilon Anchor
The Epsilon super-high holding power anchor builds upon the legendary Delta® anchor’s robustness and quality. Its concave fluke and ballast keel ensure market-leading holding power and rapid setting, while maintaining self-launching characteristics with Lewmar bow rollers and retaining the same shank geometry as the original Delta®.
Time-proven materials are used throughout the range: manganese steel or 316 stainless steel for maximum strength.
• Super-High Holding Power
• Galvanised and stainless steel versions
• Anti-snagging design
• Optional roll bar for sailboat application
• Full range from 6kg – 63kg
• Ballasted tip for fast setting
• Fully compatible with Lewmar bow rollers
Specifications
| Recommended chain size (mm) | 12 |
| Anchor weight (kg) | 50 |
| Recommended Boat size - Max (ft) | 82 |
| Recommended Boat size - Min (ft) | 70 |
| Material | Stainless Steel |
| Warranty (yrs) | Lifetime guarantee |
| A (mm) | 1175 (±24) |
| B (mm) | 520 (±10) |
| C (mm) | 20 |
| D (mm) | 890 (±18) |
| E (mm) | 479 (±10) |
| Weight (g) | 50000 |
