Mantagua NAVIPRO Compact 2 NM Combined Light (Green/Red 112.5°)
The Mantagua NAVIPRO Compact Range delivers professional-grade LED navigation lights in a sleek, low-profile design. Engineered for yachts, motorboats, and workboats up to 50 metres, these lights combine modern aesthetics with full COLREG compliance. The compact form factor makes them ideal where a discreet installation is required, while still ensuring long-range visibility and reliability.
The NAVIPRO Compact 2 NM Combined Light integrates port and starboard signalling into a single compact unit. With green (starboard) and red (port) LEDs each covering 112.5°, it provides full COLREG-compliant side lighting with a 2 nautical mile visibility range. This combined format reduces installation space and wiring, making it especially suited to modern yachts where efficiency and clean design are priorities.
Fully Wheelmark certified (MED 60427/A0) and CE approved, this light meets the highest international standards for safety and reliability. Its IP67 waterproofing, UV-resistant housing, and energy-efficient LED technology ensure robust performance and long service life with minimal power draw. The NAVIPRO range has also been tested to avoid interference with essential systems such as VHF and AIS, guaranteeing dependable operation in demanding conditions.
Key features:
- Part of the low-profile NAVIPRO Compact Range
- Combined red (port) and green (starboard) LED sidelights
- 112.5° each side, 2 NM visibility range
- COLREG compliant for vessels up to 50 m
- Wheelmark certified (MED 60427/A0) and CE approved
- Compact design: simplified installation, reduced wiring
- IP67 watertight and UV-resistant housing
- LED technology: low power draw, long service life
- Tested for zero interference with VHF and AIS systems
Specifications
| Beam angle (degrees) | 112.5 |
| Width (mm) | 69 |
| Connection | 1m Cable |
| Boat size (m) | 12-20M |
| Luminous Intensity (cd) | >5.4 |
| Visibility (NM) | 2 |
| Power (W) | 2.76 |
| Operating voltage (V) | 10-30 |
| Height (mm) | 50 |
| Warranty (yrs) | 2 |
| Water resistance | IP67 |
| Weight (g) | 170 |
| Certification | WHEELMARK 60427/A0 MED |
