Features:
High static and dynamic load capacity
Keeps lines close to the deck
Cheek cut-outs for easy bearing cleaning and maintenance
Blocks can be disassembled for servicing
Materials:
Alloy sheave and housing
Torlon® needle rollers
Black carbon Acetal ball bearings
Product information:
Ball Bearing models have Torlon® needle rollers for axial loads, and acetal ball bearings for side thrust loads.The self-contained alloy sheave packages provide reliable, low-friction performance at high loads. The high axial loads are carried by Torlon® roller needle bearings, while side thrust loads are taken up by Acetal ball bearings. Block sheave and cheeks ar
Especificaciones
| Ropes | |
|---|---|
| Cabo recomendado - Ø máx (mm) | 14 |
| Boat |
|---|
| Load | |
|---|---|
| SWL (kg) | 1990 |
| NBL (kg) | 3980 |
| Dimensions | |
|---|---|
| Ø del fijador (mm) | 10 + 8 |
| Ø de roldana (mm) | 75 |
| Weight | |
|---|---|
| Peso (g) | 352 |
