Specifications for Tylaska H8 2:1 Split Aluminium Halyard Shackle
| Ropes | |
|---|---|
| Recommended line - Max Ø (mm) | 14 |
| Recommended line - Min Ø (mm) | 10 |
| Boat | |
| Recommended Boat size - Max (ft) | 36 |
| Recommended Boat size - Min (ft) | 24 |
| Load | |
| SWL (kg) | 1810 |
| NBL (kg) | 3630 |
| Dimensions | |
| A (mm) | 84.1 |
| B (mm) | 33.5 |
| C (mm) | 7.1 |
| D (mm) | 38.2 |
| E (mm) | 21.2 |
| F (mm) | 19.3 |
| G (mm) | 15 |
| H (mm) | 1 |
| I (mm) | 31.5 |
| J (mm) | 8.1 |
| Material | |
| Material | 17-4PH |
| Weight | |
| Weight (g) | 109 |
Product specifications
are provided for guidance only, subject to error /
change and without warranty or guarantee. Refer to
manufacturer’s own datasheets / manuals for further
information.
The Tylaska Split 2:1 halyard shackle offers snatch block convenience to the popular lightweight offering from Tylaska. These are ideal for quick installation and removal from existing rigging.
