Specifications for Lewmar 15lb galv cqr® anchor welded
| Boat | |
|---|---|
| Dimensione barca consigliata - Max (ft) | 24 |
| Dimensione barca consigliata - Min (ft) | 7 |
| Dimensione catena consigliata (mm) | 6 |
| Dimensions | |
| A (mm) | 660 (±13) |
| B (mm) | 235 (±5) |
| C (mm) | 55 (±1) |
| D (mm) | 552 (±11) |
| E (mm) | 330 (±7) |
| Material | |
| Materiale | Galvinised Steel |
| Weight | |
| Peso ancora (kg) | 7 |
| Peso (g) | 7000 |
| Garanzia (anni) | Lifetime guarantee |
The C.Q.R.® anchor has gained legendary status for its superior performance. Now with fabricated galvanised construction the C.Q.R.® continues to be the blue water anchor of choice. Its hinged shank delivers consistent setting and holding even in the very worst conditions. The C.Q.R.® anchor is guaranteed for life against breakage* and has Lloyd’s Register General Approval of an Anchor Design** as a High Holding Power anchor.
*Damage by deformation or bending is not covered by this guarantee.
**Lloyd’s Test Certification is available for individual C.Q.R.® anchors by arrangement.
Sizing information is for guidance only and is subject to +/- 2% tolerance. Please contact a qualified expert for specific advice or contact the relevant Classification Society for specific certification requirements.
Specifiche
| Boat | |
|---|---|
| Dimensione barca consigliata - Max (ft) | 24 |
| Dimensione barca consigliata - Min (ft) | 7 |
| Dimensione catena consigliata (mm) | 6 |
| Dimensions | |
|---|---|
| A (mm) | 660 (±13) |
| B (mm) | 235 (±5) |
| C (mm) | 55 (±1) |
| D (mm) | 552 (±11) |
| E (mm) | 330 (±7) |
| Material | |
|---|---|
| Materiale | Galvinised Steel |
| Weight | |
|---|---|
| Peso ancora (kg) | 7 |
| Peso (g) | 7000 |
| Garanzia (anni) | Lifetime guarantee |
