Specifications for Tylaska T16S Standard bail snap shackle
| Taille bâteau recommandée - Max (ft) | 50 |
| Taille bâteau recommandée - Min (ft) | 40 |
| Style | Swivel Bail (Small) |
| Matériau | Acier inoxydable |
| Material Grade | 17-4PH SS |
| Charge de travail (kg) | 3630 |
| Charge de rupture (kg) | 7260 |
| A (mm) | 22.9 |
| B (mm) | 20.1 |
| C (mm) | 120 |
| Poids (g) | 258 |
Product specifications
are provided for guidance only, subject to error /
change and without warranty or guarantee. Refer to
manufacturer’s own datasheets / manuals for further
information.
Tylaska T16 Snap Shackles are perfect for applications requiring high strength and low weight. They have a SWL of 3,628kg and weigh only 258g in the standard bail configuration. Ideal for 40 to 50 foot boats. Standard Bails provide ample room for attaching a line while keeping weight and overall shackle length to a minimum. Ideal for halyards and sheets. Large Bails provide room for up to three additional shackles or a combination of shackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications.
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Spécifications
| Taille bâteau recommandée - Max (ft) | 50 |
| Taille bâteau recommandée - Min (ft) | 40 |
| Style | Swivel Bail (Small) |
| Matériau | Acier inoxydable |
| Material Grade | 17-4PH SS |
| Charge de travail (kg) | 3630 |
| Charge de rupture (kg) | 7260 |
| A (mm) | 22.9 |
| B (mm) | 20.1 |
| C (mm) | 120 |
| Poids (g) | 258 |
