Rutgerson block 60mm, Sliding Bearing, Single Sheave, Movable Toggle, 14mm Fork Width, 8mm Pin

https://www.upffront.com/web/image/product.template/235650/image_1920?unique=d678498

52,62 € 52.620000000000005 EUR 52,62 €

41,93 €

0% Off

Available on request

Tage
:
Std
:
Minuten
:
Sekunden
  • Marke
  • Bearing type
  • Bereich
  • Empfohlener max. Leinendurchmesser (mm)
  • Scheibe Ø (mm)
  • Anzahl der Scheiben
  • Klemme
  • Hundsfott
  • Ratsche

Diese Kombination existiert nicht.

Product Image

Rutgerson block 60mm, Sliding Bearing, Single Sheave, Movable Toggle, 14mm Fork Width, 8mm Pin

52,62 € 52,62 €
0% Off
SKU:
N/A
Shipping Info

30 Tage Geld-zurück-Garantie

 14-tägiges Rückgaberecht

 Expressversand verfügbar

Share :

Single-disc plain bearing blocks with 50mm, 60mm or 80mm disc diameter. The connection is made by a fixed or movable clevis. These blocks are used by many French mast manufacturers (Sparcraft, Z-Spar) and shipyards (Jeanneau, Bénetau and Dufour) for halyard deflection at the mast base or deck ring. Sheave-Ø Fork width Pin-Ø Working load Rope-Ø Weight 50mm 12mm 6mm 700kg 4 - 12mm 124g 50mm 14mm 8mm 700kg 4 - 12mm 130g 60mm 12mm 6mm 850kg 6 - 14mm 210g 60mm 14mm 8mm 850kg 6 - 14mm 270g 80mm 14mm 8mm 1430kg 10 - 16mm 424g

Spezifikationen

Bearing type -
Empfohlener max. Leinendurchmesser (mm) -
Scheibe Ø (mm) -
Ratsche Nein
